ลำโพงแขวนเพดาน QSC AD-P.HALO ซับวูฟเฟอร์ 6.5 นิ้ว ดอก satellite ขนาด 2.75 นิ้ว 4 ดอก 300 วัตต์ การออกแบบที่สวยงามมีคุณภาพสูงและติดตั้งง่ายไม่ยุ่งยาก Pendant-Mount Loudspeakers. จากยี่ห้อ QSC
QSC AD-P.HALO Integrated SUB/SAT Pendant Loudspeaker System
ลำโพงที่รวม SUB/SAT เอาไว้ในตู้เดียวกัน
ลำโพง Acoustic Design Series ไหม่ล่าสุดจาก QSC รุ่น AD-P.HALO ลำโพง SUB/SAT แบบแขวนที่คุณไม่เคยสัมผัสมาก่อน ด้วยการออกแบบลำโพง Subwoofer ขนาด 6.5″ และ 2-way ขนาด 2.75″ จำนวน 4 ตัว ให้อยู่ภายในตู้เดียวกัน ให้การการตอบสนองทุกย่านความถี่ การใช้งานแบบแขวนทำให้การกระจายเสียงได้รอบทิศทาง ติดตั้งง่าย ประหยัดเวลา และประหยัดเงิน มีให้เลือก 2 สี ขาว ดำ กมาะสำทรับงานติดตั้ง ที่ต้องการความเรียบง่าย และสวยงาม เช่น ร้านอาหาร สปา ฟิตนส ร้านค้า เป็นต้น
Features
- Integrated 6.5″ subwoofer and four 2.75″ satellite transducers in a single pendant-mount enclosure
- All-in-one solution with no assembly required
- 200 W RMS power rating
- Consistent tonal characteristics across the entire AcousticDesign Series family for surface, ceiling, and pendant applications
- Intrinsic Correction™ voicings available via Q-SYS Ecosystem and QSC processing amplifiers
- Rugged ABS enclosure
- Low-saturation 70 / 100 V transformers with 6 Ω bypass
- Transformer taps: 100 W, 50 W, 25 W, 12.5 W
- IP-54 ingress rating
- UL1480A and CE compliant
- Available in black (RAL 9011) or white (RAL 9010)
- Included suspension hardware and fasteners
- Complete EASE, CAD, & BIM information available online
Specifications
System Details : AD-P.HALO
LF transducer :
- 165 mm (6.5 in) dual voicecoil subwoofer, stamped basket,16 Ω nominal impedance, paper cone, paper dust cap, copper wire, rubber surround
HF transducer :
- 4x 69.85 mm (2.75 in) full-range, stamped basket, 16 Ω nominal impedance, hybrid ceramic/neodymium magnetic circuit, copper cap, paper cone, inverted aluminum dust cap, CC aluminum VC wire, rubber surround
Effective frequency range :
- 40 Hz – 20 kHz
Sensitivity :
- 86 dB
Rated noise power :
- 100 W
Max noise voltage :
- 24.5 V RMS
Coverage :
- 110° conical
Directivity index :
- 8 dB
Directivity factor :
- 6
Maximum SPL (continusous/peak) :
- 105 / 111 dB
Nominal impedance :
- 6 Ω nominal 4.9 Ω minimum @ 1.6 kHz
Crossover frequency :
- 250 Hz (2nd order low-pass + 3rd order highpass filters)
Tap power (70 / 100 V) :
- 12.5, 25, 50, 100/25, 50, 100
Port Tuning :
- 50 Hz
Input :
- 4-pin male/female Euroblock with pass-thru and locking screws
Enclosure material :
- Injection-molded ABS baffle and enclosure
Grille material :
- Stamped steel, perforated and powdercoated
Net weight :
- 10.2 kg (22.5 lb)
Product dimensions :
- Diameter 339.7 mm (13.37 in) Height: 433 mm (17.04 in)
Shipping weight :
- 12.5 kg (27.6 lb)
Shipping dimensions (W x D x H) :
- 535 x 445 x 435 mm
(21.06 x 17.52 x 17.13 in)
