JBL KX200 Full-Featured Digital Processor
JBL KX200 Full-Featured Digital Processor JBL KX200 เครื่องโปรเซสเซอร์ คาราโอเกะ JBL KX200 โปรเซสเซอร์ คาราโอเกะ จากแบรนด์ JBL
Karaoke singers require unique reverb and effects to help untrained singers sound as good as possible. The JBL KX200 dedicated karaoke processor has all the effects needed and digital signal processing (DSP) to configure input microphones and program material as well as setup any type of speaker
FEATURES
- Two separate and adjustable microphone input channels
- Optical and coaxial digital audio inputs
- USB port on the front panel for convenience
- dbx patented AFS™ (Automatic Feedback Suppressions) technology
- 15-band parameter equalizer for microphone inputs
- 8-band parameter equalizer for program inputs
- Six separate and adjustable signal outputs
- 10 custom presets and 5 factory presets
- Preloaded settings for HARMAN JBL speakers
- T9 keypad unlock screen
SPECIFICATION
| Microphone input type | XLR and ¼” balanced | |
| Impedance | 600 Ohm | |
| EIN | < -80 dBu, 20 KHz bandwidth | |
| Level Control | – ∞ to +14.2 dBu | |
| Line Input | Left & right channel RCA unbalanced | |
| Line Input Impedance | 24 K Ohm | |
| XLR Output | Balanced or Unbalanced | |
| XLR Output Impedance | 30 Ohm balanced, 15 Ohm unbalanced | |
| RCA Output | Left and Right Channel Unbalanced | |
| RCA Output Impedance | 100 Ohm | |
| Frequency Response | 20 Hz – 20 KHz, +/- 1 dB | |
| THD + N | < 0.007% 20 Hz – 20 KHz | |
| Dynamic Range | > 103 dB | |
| Analog / Digital Signal Conversion | 24 bit, 48 KHz | |
| Processor | 32 bit | |
| Computer Connection | USB 2.0 | |
| Dimensions (H x W x D): | 44.20 mm x 440.54 mm x 139.25 mm | |
| Shipping Weight: | 2.5 kg | |
| Net Weight: | 1.8 kg |
