JBL KX180 Professional-Grade Digital Processor เครื่องโปรเซสเซอร์ คาราโอเกะ JBL KX180 โปรเซสเซอร์ คาราโอเกะ จากแบรนด์ JBL
JBL KX180 Professional-Grade Digital Processor
- 15-Band PEQ และ Compressor สำหรับ Mic input
- 3 Levels กับการป้องกันกาดเกิด Feedback สำหรับ Mic input
- ช่องทาง RCA Connectors และ Optical Connector สำหรับใช้งาน Music Input
- 6 Output Channels : Right, Left , Centre , Sub , Surround Left
- มาพร้อมช่องทางสำหรับ REC Channels ที่เป็นแบบ Stereo
- รองรับการ Storage และ Recall ได้มากถึง 10 Presets
Professional-Grade Digital Processor
KX180 is a professional-grade digital processor designed for karaoke applications and provides a full set of audio processing for enhancing or fine-tuning music and voice. KX180 is equipped with three 6.5mm connectors for microphone input, two groups of RCA connectors and an optical connector for music input, and one pair of RCA connectors for recording out. It supports storage and recall of up to 10 presets and manual or auto control of Dance or Sing mode.
คุณสมบัติ
- Two groups of microphone inputs
- 15-band PEQ and compressor for each Mic Input
- Three levels of Feedback Inhibition for each Mic Input
- Independent control of Echo and Reverberation
- Two pairs of RCA connectors and an Optical connector for Music Input
- 15-band PEQ for Music Input
- Three levels of Excitement for Music Input
- Six output channels: Right, Left, Centre, Sub, Surround Right and Surround Left.
- 10-band PEQ for Right and Left Outputs
- 7-band PEQ for Surround and Centre Outputs
- 5-band PEQ for Subwoofer Output
- Compressor provided for each output channel
- Two independent REC channels can be paired into stereo
- Authority control for front panel controls
- Up to 10 presets can be saved
- Dance or Sing mode of each microphone input channel can be switched manually or automatically
APPLICATIONS
- Professional tool designed for karaoke applications.
สเปค
Mic Input Type |
3 x 1/4” unbalanced |
|
Impedance |
7.5K Ohms |
|
EIN |
<-110dBu, 20KHz Bandwidth |
|
Level Control |
–∞ to +0.8dBu |
|
Line Input Type |
RCA unbalanced, left & right |
|
Impedance |
10K Ohms |
|
XLR Output Type |
Unbalanced |
|
Level |
0dBu Nominal, +14.2dBu Maximum |
|
Impedance |
50 Ohms |
|
RCA Output Type |
Unbalanced, left & right |
|
Level |
﹢17.6dBu Maximum@Mic input,
|
|
Impedance |
115 Ohms |
|
Frequency Response |
20Hz~20KHz ≤ ±1.0dB |
|
THD+N |
<0.06% 20Hz to 20KHz |
|
Dynamic Range |
>100dB |
|
A/D Conversion |
24bit, 48KHz |
|
DSP Processor |
High performance 32-bit/40-bit floating-point processor |
|
Carrier Frequency |
38KHz |
|
Format |
NEC |
|
Distance |
Device dependent |
|
Angle |
Device dependent |
|
Computer Connection |
USB 2.0 |
|
AC Power Supply |
AC 220V/50Hz |
|
Dimensions (W X D X H) |
485 X 205 X 47mm |
|
Net Weight |
2.8Kg |
|
Gross Weight |
3.47Kg |
